Auto focus Range:+15~-20mm(FL150),+20~-25mm(FL200)
Acceleration:≤10m/s2
Velocity :≤15m/minAccuracy :≤ 50 µm
Collimator Focal length 100mm
Focusing Focal length 150mm/200mm
Cover glass size
Collimation side: Φ38mm×1.5mm
Focusing Side : Φ37mm×7mm
Assist gas pressure <30bar
Weight 6.5kg
Nhà sản xuất: Raytools
Đầu Cắt Raytools BM116
Power Rating Fiber laser≤8KW
Clear Aperture 35mm
Auto focus Magnification of Spot :1.2~2.0xRange:+08~-12mm(1.2X) +15~-20mm(2.0X) Acceleration:≤10m/s2
Velocity :≤10m/min
Accuracy :≤ 50 µm
Cover glass size Collimation side: Φ38mm×1.5mm
Focusing Side : Φ37mm×7mm
Protective glass: Φ50mm×2mm
Assist gas pressure <25bar
Weight 6.5kg
Nhà sản xuất: Raytools
Đầu Cắt Raytools BT210S
Công suất ≤1500W
Clear Aperture 25mm
Collimator Focal length 75mm/100mm
Focusing Focal length 100mm/125mm
Gương bảo vệ φ24.9mm*1.5mm(CM)
φ27.9mm*4.1mm(FM)
Assist gas Pressure ≤20bar
Khối lượng ~2.3kg
Nhà sản xuất: Raytools
Đầu Cắt Raytools BT240S
Power Rating ≤3.3KW
Clear Aperture 28mm
Collimator Focal length 100mm
Focusing Focal length 125mm/155mm/200mm
Cover glasses φ24.9mm*1.5mm(CM)
φ27.9mm*4.1mm(FM)
Assist Gas Pressure ≤25bar
Weight ~3.5kg
Height Sensor(EtherCAT or ±10V optional)
Distance Range(1mm Recommended) 0.3-10mm
Calibration Auto Calibrating/Manual Calibrating
Response Time <1ms
Temperature Stability In the range of 0 to 45℃, the temperature stability is in the range of ±5%
Power Requirement 24V
Output (linear or optimization curve signal) 0~10V/+-10V Analog
Nhà sản xuất: Raytools
LECI chuyên cung cấp các dòng sản phẩm, linh kiện Laser Fiber chính hãng. Hỗ trợ kỹ thuật, sửa chữa máy và các thiết bị laser uy tín và chất lượng.
Liên hệ tư vấn và đặt hàng (24/7)
Công ty TNHH LECI Phòng 1901, Tòa nhà Saigon Trade Center, Số 37 Tôn Đức Thắng, Phường Bến Nghé, Quận 1, Thành phố Hồ Chí Minh, Việt Nam Phone: 02822202988 Hotline: (+84) 0938746286 (Zalo, Whatsapp) Website: www.lecilaser.com
Mô tả
LECI cung cấp các loại Đầu cắt Raytools như Đầu Cắt Raytools BM109, Đầu Cắt Raytools BM114S, Đầu Cắt Raytools BM115, Đầu Cắt Raytools BM116, Đầu Cắt Raytools BT210S, Đầu Cắt Raytools BT240S, Đầu cắt Raytools BS08K
Đầu Cắt Raytools BM109
Đầu Cắt Raytools BM114S
Nhà sản xuất: Raytools
Đầu Cắt Raytools BM115
Nhà sản xuất: Raytools
Đầu Cắt Raytools BM116
Nhà sản xuất: Raytools
Đầu Cắt Raytools BT210S
Nhà sản xuất: Raytools
Đầu Cắt Raytools BT240S
Nhà sản xuất: Raytools
